SFA Series Multi-functional SF6 Analyzer for SF6 Purity, SO2, H2S, CO, HF, CF4, N2, O2 Testing

SFA Series Multi-functional SF6 Analyzer can test dew point, micro-water content(ppm), SF6 purity, the concentration of SO2, H2S, CO, HF, etc.

1. Model SFA-I can test SF6 purity, dew point, water content, SO2, H2S;

2. Model SFA-II can test SF6 purity, dew point, water content, SO2, H2S, CO;

3. Model SFA-III can test SF6 purity, dew point, water content, SO2, H2S, CO, HF;

4. Model SFA-IV can test SF6 purity, dew point, water content, SO2, H2S, CO, HF, CF4;

5. Model SFA-V can test SF6 purity, dew point, water content, SO2, H2S, CO, HF, CF4, N2, O2;

Specifications:

Features:

• Fast and save gas: It can complete the detection for water content, purity and gas concentration simultaneously. After set-up and start the test, the measuring time of dew point is about 5min and SF6 purity and gases concentration is about 2min;

• Self-lock joint: The self-lock joint is imported from German which is safe, reliable and without gas leakage.

• Data storage: It can store 200 groups test results.

• Curve display: Large-screen curve display the process of dew point measurement;

• Clearly display: Dew point, micro-water(ppm), SF6 purity, SO2, H2S, CO(optional) and HF(optional) concentration, temperature, humidity, time, date, etc, are displayed by LCD.

• Built-in power supply: built-in 4Ah chargeable lithium battery, can work for 10 hours.
